SUN-14/15/16/18/20K-SG05LP3-EU-SM2 New Deye Hybrid Solar Inverter 15KW 16KW 18KW 20KW 380V 400V

Deye New Hybrid Solar Inverter Three Phase 380V 400V

SUN-14/15/16/18/20K-SG05LP3-EU-SM2


  • Item NO.:

    SUN-14/15/16/18/20K-
  • Product Origin:

    China
  • Shipping Port:

    Ningbo, Shanghai, Shenzhen
  • Lead Time:

    10-20days
  • Type:

    deye hybrid inverter
  • Output Voltage :

    380V -400V
  • Item No:

    Three Phase
  • Inverter Power:

    14-20KW
  • Certification:

    CE, TUV, IEC, UL, VDE,,,,etc
  • Lead Time:

    In Stock
  • Payment:

    T/T; West Union; West Union; Paypal and so on
  • Warranty:

    10 years
Product Details

SUN-14/15/16/18/20K-SG05LP3-EU-SM2 New Deye Hybrid Solar Inverter 15KW 16KW 18KW 20KW 380V 400V


SUN-20K-SG05LP3 -EU-SM2


deye 20kw hybrid inverter

Specifications of DEYE new hybrid solar inverter 15KW 16KW 18KW 20KW

Model
SUN-15K-SG05LP3-EU-SM2
SUN-16K-SG05LP3-EU-SM2
SUN-18K-SG05LP3-EU-SM2
SUN-20K-SG05LP3-EU-SM2
Battery Type
Lead-acid or Lithium-ion
Battery Voltage
40-60V
Max Charge
280A
300A
330A
350A
Max Discharge
280A
300A
330A
350A
NO of Battery Input
1
Max PV Input Power
22500W
24000W
27000W
30000W
Max PV Input Voltage
800V
Start-up Voltage
160V

Max Operating PV

Input Current

36A+20A
Max Input Short-Circuit Current
54A + 30A
No of MPP Trackers
2
No of Strings MPP Tracker
2+1
AC Input/Outpur Power
15000W
16000W
18000W
20000W
Max AC Input/Output Power
16500W
17600W
19800W
22000W
AC Input/Outpur Current
22.8/21.8A
24.3/23.2A
27.3/26.1A
30.4/29A
Max AC Input/Outpur Current
22.8/21.8A
24.3/23.2A
27.3/26.1A
30.4/29A
Max Continuous AC Passthrough
70A
Peak Power (Off-Grid)
2 times of rated power, 10s
Input/Output Voltage
220/380V, 230/400V
Grid Connection Form
3L + N + PE
Communication
RS485/RS232/CAN
Protection Rating
IP65
Weight
50.6 KG
Cabinet Size (W*H*D mm)
456*750*268.5
Warranty
5 Years/10 Years

As a long-term partner of DEYE inverter, we GREENSUN have become the official authorized dealer of DEYE.

We can provide all the products listed on the DEYE official website, including energy storage inverters, energy storage batteries, etc.
Also including DEYE's latest 14KW 15KW 16KW 20KW energy storage inverter (SUN-14/15/16/18/20K-SG05LP3-EU-SM2).
All inverters sold by us enjoy direct after-sales service from DEYE, whether it is replacing the whole machine or replacing parts.

In addition, our GREENSUN's own lithium batteries, ordinary 48V 51.2V low-voltage lithium batteries and HV high-voltage lithium batteries are all in the DEYE official list and support communication with DEYE inverters.

At the same time, DEYE provides communication services and after-sales for lithium battery brands certified by DEYE. DEYE does not provide any after-sales support for lithium batteries that are not certified by DEYE.

Compared with the old version of DEYE energy storage inverter, the new 14KW 15KW 16KW 18KW 20KW hybrid inverter can withstand larger solar panel current and is smaller in size.
